INTESIS Panasonic ECOi and PACi systems

INTESIS Panasonic ECOi and PACi systems

Regular price $485.00 AUD
Regular price Sale price $485.00 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.
  • We use Australia Post Carbon Neutral Shipping: 2-5 Days $9.99, 1-3 Days $15 or StarTrack Premium $20
  • Order before Midday and we Dispatch the same day
  • Found a Cheaper Price we will Match it

Panasonic ECOi and PACi systems to AC Cloud Control (WiFi) Interface - 1 unit

This model allows you to control your AC unit from the AC Cloud app and also integrates with HomeAssistant

The gateway is wired directly to an indoor unit. This allows not only the control of the main AC functions such as operating mode, fan speed, temperature setpoint, but the monitoring of errors and alarms.

Panasonic offered the capability to integrate their ECOi and PACi air conditioning systems with AC Cloud Control through a WiFi interface for remote control and monitoring. Here's a general overview of how this system works and some potential features:


  • Remote Control and Monitoring: Panasonic's AC Cloud Control system, when integrated with ECOi and PACi systems, enables users to remotely control and monitor their air conditioning units. This feature allows users to manage their HVAC systems from their smartphones, tablets, or computers, providing convenience and flexibility.


  • Mobile App Control: Panasonic typically provides a dedicated mobile application that users can install on their smart devices. This app allows users to control various aspects of their Panasonic ECOi and PACi air conditioning systems. Key features accessible through the app may include:

    • Temperature adjustments.
    • Mode settings (cooling, heating, fan-only, etc.).
    • Fan speed control.
    • Zone or room selection (for multi-zone systems).
    • Setpoint scheduling for customized comfort.
  • Energy Efficiency: Some Panasonic systems integrated with AC Cloud Control may offer energy consumption data and recommendations. Users can use this information to make more energy-efficient choices, reduce operating costs, and track their system's performance over time.

  • Filter Status Notifications: The app may provide filter status notifications, alerting users when it's time to clean or replace the air filters. Maintaining clean filters is essential for indoor air quality and the efficient operation of the HVAC system.

  • Diagnostic Alerts: In case of system issues or malfunctions, the app may send diagnostic alerts. These alerts often include error codes and other information that can be shared with HVAC technicians for remote troubleshooting, potentially saving time and service costs.

  • Compatibility: Panasonic aims to ensure compatibility between their ECOi and PACi air conditioning systems and the AC Cloud Control system. However, it's essential to confirm compatibility with specific models and requirements for your installation.

Technical Details

Enclosure: ABS (UL 94 V-0). 2,5 mm thickness

Dimensions: 70 x 100 x 28 mm

Weight: 103 g

Colour: White

AC Connector: 14V, 54mA typical

Power Supply: 12DCV, 100mA

Radio Parameters: RF Frequency range: 2412 to 2484 MHZ Output power (typical): 14/20 dBm

WIFI: 802.11 b/g/n (802.11n up to 150 Mbps)

Mounting: Wall

LED indicators: 1 x Device status

Operating Temperature: From 0oC to 40oC

Operating Humidity: <93% HR, no condensation

Stock Humidity: <93% HR, no condensation

RoHS Conformity: Compliant with RoHS directive (2011/65/CE).

Certifications: CE conformity to EMC directive (2014/53/EU) ¥ EN 62368-1:2014 ¥ CSA/UL 62368-1:2014 ¥ AS/NZS 62368.1:2018 ¥ EN 300 328 V2.1.1 ¥ EN 303 446-1 V1.2.0 ¥ Regulations: FCC/IC. Standards: Title 47 CFR Part 15B ICES-003 (Issue 6)


Technology Data
Mounting Surface
product_subtype Interfaces


Compatibility checker

Intesis product information page & Datasheet
