FIBARO D/W Sensor 2 (Dark Brown)
FIBARO D/W Sensor 2 (Dark Brown)
- We use Australia Post Carbon Neutral Shipping: 2-5 Days $9.99, 1-3 Days $15 or StarTrack Premium $20
- Order before Midday and we Dispatch the same day
- Found a Cheaper Price we will Match it
The FIBARO Z-Wave D/W Sensor 2 (Dark Brown) is a small, battery-powered magnetic door and window sensor with a built-in temperature sensor.
- Completely wireless
- Automatic software updates
- Includes a built-in temperature sensor
- Tamper and low battery alarm notification
Product Details
The FIBARO Z-Wave D/W Sensor 2 is a smart magnetic door/window sensor capable of sending binary ON/OFF commands wirelessly using the Z-Wave network (AUS/NZ version 921.42 MHz) when it is triggered.
The detector consists of two magnetic units, one is placed on the moving part of the door or window and the other on the frame. The sensor expands the capabilities of your Z-Wave system by monitoring the opening of doors, windows and garage doors.
The FIBARO Z-Wave D/W Sensor 2 can be used to automatically turn on lights, turn wireless switches ON/OFF and for security applications within the Z-Wave network. It is also useful for climate control systems, monitoring whether any doors or windows are open to ensure that your air-conditioning is not operating when it is not efficient to do so.
This sensor includes a built in temperature sensor which further extends your Z-Wave network's climate control capablities by allowing it to detect the exact temperature in your home.
This product comes in multiple different colours.
Note: This device is currently only compatible (out of the box) with Fibaro Home Center 2 and Fibaro Home Center Lite controllers.
To enable this device to work with Vera controllers you need to do the following:
Under the devices Advance>Params you need to change the following details:
device_type - urn:schemas-micasaverde-com:
device_file - D_DoorSensor1.xml
device_json - D_DoorSensor1.json
After all the details are confirmed by the system you will need to go to New service and press Reload Engine after this you will need to wait for the device to reconfigure before it will appear in your system, but once it has it should appear as a D/W sensor in the Vera UI.
Product Support
Manuals:
⇒FIBARO Z-Wave Door/Window Sensor User Manual
Technical Specifications
RF Protocol
|
Z‐Wave Plus (500 series chip)
|
RF Frequency
|
921.42Mhz ‐ AU/NZ approved RF for Z‐wave
|
Z‐Wave device type
|
Z-Wave binary sensor, multilevel command supported
|
Power
|
One battery, type ER 14250 1/2AA 3.6V (included)
|
Operation Range
|
Up to 30m without obstacles
|
Application
|
Indoor use only
|
Operation temperature
|
0 ~ 40 °C
|
Temperature Measuring Accuracy
|
±0.5°C
|
Temperature Measuring Range
|
0 ~ 60°C
|
Weight
|
70g
|
Housing
|
ABS
|
Dimensions
|
(LxWxH) 71mm x 18mm x 18mm
|
Compliance
|
AS/NZS 4268:2003+A1+A2
|
Regulatory Compliance Mark | Z1535 |
