Buy 10 Shelly Plus 1PM WiFi-operated relay switch, 1 channel 16A, with Power Metering Get 1 Free
Control and measure power consumption for a wide range of home appliances and office equipment (lights, power lines, security systems, heating radiators, air conditioners, etc.) from anywhere with the smallest WiFi-operated relay switch, with Bluetooth connection
- Wi-Fi connectivity: Connects to your Wi-Fi network.No HUB required!
- Bluetooth: Add devices quickly and easily via Bluetooth connection, using the Shelly Cloud App.
- Power metering with data storage
- Wide range of voltages supported
- Extremely fast processor: ESP32
- Enhanced safety: overpower, overvoltage, and over-temperature protection
- Enhanced security: MQTT and WSS support, TLS, and custom certificates support
- Improved API interface
Next Generation Shelly
Enjoy supreme home automation and control with the new generation Shelly devices - Shelly Plus!
Shelly smart relays now come with perfected electrical appliance control through an extremely fast processor, quicker connectivity, improved integration, and enhanced safety! You can now add devices easily via Bluetooth connection, using the Shelly Cloud App. Shelly Plus line supports TLS encryption and has an improved shell for standardized support for external sensor plugs.
WARNING:
All electrical work must be carried out by a licensed electrician under the electrical safety act and AS/NZS300. Doing your own electrical can be dangerous.
| POWER | |
| Power supply AC | 110-230V ±10%, 50/60Hz |
| Maximum load | 16A |
| Power supply DC | 24 – 240V |
| SPECIAL FUNCTIONS | |
| Dry contacts | No |
| Roller shutter mode | No |
| Device temperature protection | Yes |
| Overload protection | Yes |
| Power measurement | Yes |
| Working without a neutral line | No |
| FEATURES | |
| HTTP/HTTPS webhooks | Yes |
| Custom scripts(mJs) | Yes |
| Channels | 1 Channel |
| Operational temperature | 0°C to + 40 °C |
| Device power consumption | < 1 W |
| Intelligent On/Off | Yes |
| Local and remote control | Yes |
| Sunrise/Sunset | Yes |
| Weekly Schedule | Yes |
| UL Listed option | No |
| CONNECTIVITY | |
| Wireless | Yes |
| Wi-Fi Protocol | 802.11 b/g/n |
| Wi-Fi Radio frequency | 2412 - 2484 MHz |
| Wi-Fi Radio signal power | 1mW |
| Wi-Fi Range | up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
| Bluetooth | Yes |
| DIMENSIONS | |
| Size | 41mm x 36mm x 15mm |
